91 pump octane minimum (R+M/2 Method) or 95 RON minimum, E5, E10
Exhaust System
Split exhaust with Resonator
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, Multi-Plate, Assist
Gearbox
6 Speed / Constant Mesh
Primary Drive Ratio
1:564:1
Final Drive
Belt Drive, 152 Tooth
Assist & Slipper Clutch
Yes
Electrical & Electronics System
Battery
12 Volt, 18 amp/hour, 310 CCA, Sealed Glass Mat
Alternator/Generator
710W @ 3500 RPM
Headlight Type
Non-Serviceable Reflective LED
Taillight Type
Non-Serviceable Reflective LED
Instrumentation
Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation.
A 7″ Display Powered by RIDE COMMAND with Customizable Gauge Screens, Bluetooth® Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Turn-by-Turn GPS Navigation, Live Weather and Traffic Overlays, Apple CarPlay®, Bike Health, Bike Locator, Intuitive Destination Search, and More
Riding Modes
3 Ride Modes – Standard, Tour, Sport
Traction Control System
Yes
ABS
Yes
Cruise Control
Yes
Chassis & Suspension
Front Suspension
43 mm Inverted Telescopic Fork
Front Suspension Travel
130 mm / 5.1 inches
Rear Suspension
Single Shock w/ Hydraulic Preload Adjustment
Rear Suspension Travel
114 mm / 4.5 inches
Rake
25 °
Trail
150 mm / 5.9 inches
Swingarm
Steel
Wheels & Brakes
Wheels
5-Spoke Precision Machined Cast
Front Wheel/Rim Size
3.5 x 19″
Front Tire Size
130/60B19 66H Metzeler® Cruisetec
Rear Wheel/Rim Size
5 x 16″
Rear Tire Size
180/60R16 80H Metzeler® Cruisetec
Front Brakes
Brembo® Calipers, Dual Semi-Floating Rotors: 320mm x 5.0mm
White Crystal with Black Candy, Red Candy, and Gloss Black
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
