An exceptional evolution of the pioneering Norden 901, the Norden 901 Expedition is assembled with all the Technical Accessories necessary to make it the ideal expedition motorcycle. Comfort is significantly boosted by the offroad-specific WP XPLOR suspension that offers longer travel, 240 mm front and rear, and is fully adjustable for a personalised set-up. A heated seat and grips make cold-climate riding comfortable at all times while a Touring Windshield reduces fatigue by deflecting wind around the rider. The Side Bag Set allows all the travel essentials to be securely stowed while the Connectivity Unit in front of the handlebars provides accurate directions thanks to the Turn-by-Turn+ navigation. Designed and built to reach the most remote destinations, this highly reliable and technically enhanced touring machine is characterised by the distinctive colour scheme applied to its ergonomic bodywork. Built for pioneers, your next journey starts with the Norden 901 Expedition.
Key Specifications
Engine Type
2-cylinder, 4-stroke, parallel twin
Engine Capacity
54.3 cubic inches / 889 cc
Max Power
77 kw / 103.3 hp
Max Torque
73.8 ft-lb / 100 nm
Fuel Tank Capacity
5.0 US gallons / 19 L
Weight (Wet/Kerb)
502.2 lbs / 227.8 kg
Seat Height
Low position – 34.9 inches / 887 mm Standard position – 35.7 inches / 907 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Husqvarna Norden 901 Expedition
Year
2026
Engine
Engine Type
2-cylinder, 4-stroke, parallel twin
Displacement
54.3 cubic inches / 889 cc
Bore x Stroke
90.7 x 68.8 mm
Compression Ratio
13.5 : 1
Max Horsepower
77 kw / 103.3 hp
Max Torque
73.8 ft-lb / 100 nm
Engine Management System
Bosch EMS with RBW
Fuel-mixture System
DKK Dellorto (Throttle body 46mm)
Lubrication System
Forced oil lubrication with 2 oil pumps
Cooling System
Liquid cooled with water/oil heat exchanger
Ignition System
Electric starter
Performance
Fuel Consumption
52.3 mpg / 4.5 L / 100km
*n/a – information not provided by manufacturer
Transmission
Clutch
Cable operated PASC slipper clutch
Gearbox
6-speed
Primary Drive Ratio
39:75
Secondary Drive Ratio
16:45
Final Drive
520 X-Ring
Quick Shifter
Easy Shift
Traction Control System
Cornering Motorcycle Traction Control
Electrical & Electronics System
Battery
12V 10 Ah
Starter
Electric starter
Headlight Type
LED
Taillight Type
LED
Instrumentation
5 inch TFT screen
Riding Modes
Street, Rain, Offroad, advanced Explorer
Traction Control System
Cornering Motorcycle Traction Control
ABS
Bosch ABS System
Cruise Control
Standard
Chassis & Suspension
Frame Type
Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Front Suspension
WP XPLOR-USD, Ø 48 mm, fully adjustable
Front Suspension Travel
9.45 inches / 240 mm
Rear Suspension
WP XPLOR-Monoshock, fully adjustable
Rear Suspension Travel
9.45 inches / 240 mm
Steering Damper
Yes
Wheels & Brakes
Wheels
Spoked wheels with aluminium tubeless rims
Front Wheel/Rim Size
2.50 x 21 inch
Rear Wheel/Rim Size
4.50 x 18 inch
Front Brakes
2 x 4-piston caliper, radially mounted, brake disc (320 mm), J Juan
Rear Brakes
2 piston floating caliper, brake disc (260 mm), J Juan
ABS
Bosch ABS System
Dimension & Weights
Seat Height
Low position – 34.9 inches / 887 mm Standard position – 35.7 inches / 907 mm
Wheelbase
60.20 inches / 1,529 mm
Ground Clearance
10.63 inches / 270 mm
Fuel Tank Capacity
5.0 US gallons / 19 L
Wet (kerb/curb) Weight
502.2 lbs / 227.8 kg
Features
Heated grips and seats.
Tubeless wire spoked design
Touring Windshield
Ride Modes
Easy Shift
Off-road ABS
Cruise Control
MTC
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
