Honda NC750X DCT (2025)

2025-Honda-NC750X-DCT-5-throttlecraze.com

There’s a great gratification that comes with riding one bike that can do it all—a trusted companion you know better and better with every ride. Lockable integrated storage and our automatic Dual-Clutch Transmission (DCT) make the NC750X an excellent choice for everyday riding. New this year: dual-disc front brakes and a five-inch TFT instrument display with Honda RoadSync compatibility.

Key Specifications

Engine TypeLiquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder
Engine Capacity745 cc / 45.5 cubic inches
Max Power43.1 kW (57.8 hp) @ 6,750 rpm
Max Torque69 Nm (50.9 ft-lb) @ 4,750 rpm
Fuel Tank Capacity3.7 US gallons / 14.1 L
Weight (Wet/Kerb)497 lbs / 226 kg
Seat Height31.6 inches / 802 mm
2025-Honda-NC750X-DCT-4-throttlecraze.com

All Specifications

Make & Model

ModelHonda NC750X DCT (NC750XD)
Year2025

Engine

Engine TypeLiquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder
Displacement745 cc / 45.5 cubic inches
Bore x Stroke77.0 x 80.0 mm
Compression Ratio10.7 : 1
Number of Cylinders2
Max Horsepower43.1 kW / 57.8 hp @ 6,750 rpm
Max Torque69 Nm / 50.9 ft-lb @ 4,750 rpm
Valve TrainSOHC; four valves per cylinder
Valves per Cylinder4
Ø throttle valve36 mm
Engine Management SystemPGM-FI electronic fuel injection
Cooling SystemLiquid Cooled
Ignition SystemComputer controlled digital transistorised with electronic advance
Emissions Compliance82 g/km CO2; Meets CARB and EPA standards.

Performance

Fuel Consumption~ 67.2 mpg / 3.5 L/100km

Transmission

ClutchWet multiplate clutch (DCT)
Gearbox6-speed Dual Clutch Transmission (DCT)
Final Drive#520 Chain; 17T/41T

Electrical & Electronics System

Battery12V/11AH/11.6 Ah
StarterElectric
Headlight TypeLED
Taillight TypeLED
InstrumentationLCD Meter, with speedometer, bar-type tachometer
Traction Control SystemHonda Selectable Torque Control (HSTC)
ABSStandard (details not specified)

Chassis & Suspension

Frame TypeDiamond; steel pipe
Front Suspension41mm telescopic fork
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionMonoshock damper, Pro-Link swingarm
Rear Suspension Travel4.7 inches / 120 mm
Rake27.0 °
Trail4.3 inches / 110 mm
SwingarmPro-Link swingarm

Wheels & Brakes

WheelsMulti-spoke cast aluminium
Front Wheel/Rim Size17 inch
Front Tire Size120/70ZR-17M/C (58W)
Rear Wheel/Rim Size17 inch
Rear Tire Size160/60ZR-17M/C (69W)
Front BrakesAxial mounted twin-piston brake caliper, 296 mm floating double disc
Rear Brakes240mm single wavy hydraulic disc with single-piston caliper
ABSStandard (details not specified)

Dimension & Weights

Overall Length87.0 inches / 2,210 mm
Overall Width33.3 inches / 846 mm
Overall Height52.4 inches / 1,330 mm
Seat Height31.6 inches / 802 mm
Wheelbase60.4 inches / 1,535 mm (DCT)
Ground Clearance5.7 inches / 145 mm
Fuel Tank Capacity3.7 US gallons / 14.1 L
Wet (kerb/curb) Weight497 lbs / 226 kg

Features

  • Parallel-twin engine
    • The engine’s twin-cylinder format produces ample low- and mid-range torque, and its 270-degree-phase crank and uniaxial primary balancer make it smooth.
  • Electronic fuel injection
    • With electronic fuel injection, starting your bike on cold mornings is easier, and the engine runs flawlessly even at higher elevations.
  • Front suspension
    • You get a perfect balance between a long-distance and a short-hop street machine. This gives it a wide range of capabilities and good handling that helps inspire confidence.
  • Disc brakes with combined ABS
    • Now with dual-front and single-rear disc brakes featuring our Anti-Lock Braking System (ABS), you get stronger, more predictable stopping power, even under challenging conditions.
  • Pro-Link® rear suspension
    • When partnered with a Honda Multi-Action System (HMAS) rear shock, Pro-Link® rear suspension effectively handles uneven surfaces for a smoother ride.
  • Steel truss frame
    • With a rigid and compact chassis that is both light and strong, you get precise handling along with a supple ride.
  • Cast aluminium wheels
    • The 17-inch wheels significantly aid in responsive handling. The cast wheels are light, robust, and feature a new design for this year, adding to the bike’s aesthetic appeal.
  • Honda Selectable Torque Control (HSTC)
    • With Honda Selectable Torque Control (HSTC) and four ride modes, you can choose the appropriate level of performance for everything from dirt to gravel to all kinds of pavement.
  • Automatic Dual-Clutch Transmission (DCT)
    • Our automatic Dual-Clutch Transmission lets you shift with the push of a button, or you can let the bike shift itself automatically. In addition, DCT offers three riding modes, depending on the performance you want.
  • Throttle-by-wire
    • Throttle-by-wire (TBW) technology allows for four selectable engine power-delivery modes: Standard, Rain, Sport, and an additional user-customizable setting.
  • Streamlined cowl
    • Revised for 2025, the bike’s cowl provides ample wind protection and has a fresh, angular design with clean, sharp edges.
  • Low-profile windscreen
    • This bike offers just the right amount of bodywork—enough to offer good wind protection but not so much that it feels heavy or wide.
  • Integrated storage
    • A spacious utility compartment in front of the rider is big enough to accommodate most full-face helmets with a visor and other essentials. It’s secure, convenient, and fully integrated into the bike’s design.
  • Under-seat fuel tank
    • The fuel tank is located under the seat for more centralized mass and improved handling. This unique design also makes room for our integrated storage compartment.
  • Low seat height
    • The low seat height helps make this bike more rider-friendly in stop-and-go traffic as well as parking lots.
  • Extra comfortable seat
    • If you plan to take longer trips, you’ll really appreciate this seat. It’s supportive enough for precise riding, yet comfortable even when you’re sitting on it for hours.
  • LCD instrument panel
    • Full digital LCD instrumentation includes a speedometer, bar-type tachometer, clock, low-fuel gauge, and two trip meters. The tach bar graph also changes color based on fuel consumption, rpm, gear position, and more.
  • Honda RoadSync
    • Honda RoadSync connects to your Android or iOS device via Bluetooth and the Honda RoadSync app. It allows for hands-free navigation, music playback, as well as the ability to check local forecasts at your destination. Android phones can link for hands-free calling and texting.

Honda NC750X DCT (2025) Color Options

  • Matte Pearl White (US)
  • Fighting Red (EU)
  • Matte Pearl Glare White (EU)
  • Earth Khaki (EU)
  • Earth Black (EU)
  • Matte Deep Mud Gray (EU)
2025-Honda-NC750X-DCT-3-throttlecraze.com
2025-Honda-NC750X-DCT-2-throttlecraze.com
2025-Honda-NC750X-DCT-1-throttlecraze.com

more Specifications
