300 mm Disc, Dual floating rotors, 32 mm, 4-piston fixed caliper, Reflex Linked Brembo
Rear Brakes
270 mm Disc, fixed rotor, 32 mm, 4-piston fixed caliper, Reflex Linked Brembo
ABS
ABS, C-ABS
Dimension & Weights
Overall Length
2595.8 mm / 102.2 inches
Seat Height
690.88 mm / 27.2 inches (laden weight with 81.6 kg / 180 lb operator)
Wheelbase
1625 mm / 64 inches
Ground Clearance
129.54 mm / 5.1 inches
Fuel Tank Capacity
22.7 L / 6 US gallons
Wet (kerb/curb) Weight
422.7 kg / 932 lbs
Infotainment
System Name
Boom!™ Box GTS
Display
6.5″ Full Color TFT Touchscreen
Audio Output
25W x 4 channels (100W total)
Speaker Configuration
4 x 5.25″ Standard Speakers
Headset Compatibility
16-64 ohm impedance
Radio Support
AM/FM/Weather Band
Media Playback
SD Card, USB Flash Drive, MP3 via USB
System Languages
English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, Portuguese (Portugal/Brazil), Russian, Czech, Polish, Dutch, Turkish, Japanese, Korean, Chinese (Simplified), Thai, Indonesian, Arabic
Bluetooth Features
Hands-free calling, Media streaming
Voice Control
Phone functions: Device-dependent
Intercom System
Standard (Passenger headset sold separately)
Vehicle Data Display
Air temperature, Oil pressure, EITMS status
Text-to-Speech
Device-dependent language support
USB Connectivity
Supports USB/MTP, iPod/iPhone connectivity
Smartphone Integration
Bluetooth phone/media connectivity
Rider Safety Enhancements
ABS (Anti Lock Braking System)
ABS is designed to prevent the wheels from locking under braking and helps the rider maintain control when braking in a straight-line, urgent situation.
ELB (Electronic Linked Braking)
This feature electronically applies braking effort to both wheels when the rider applies the front brake lever and, on some models when the rider applies the rear brake pedal. ELB can help many riders achieve better braking performance. It boosts braking power when needed while minimizing or stopping the linking for lighter braking or at lower speeds.
VHC (Vehicle Hold Control)
With Vehicle Hold Control (VHC), your bike’s not rolling anywhere until you’re ready to go. Perfect for hill starts or ramps, VHC keeps the brakes locked after you let go, giving you a smooth, confident launch. Just give the brake lever or pedal a quick squeeze at a stop, and VHC has you covered until you’re ready to roll. Heads up: this isn’t a parking brake replacement, but it sure makes those uphill take-offs a breeze.
TPMS (Tire Pressure Monitoring System)
TPMS alerts the rider through the information display to low or high tire air pressure. Maintaining proper tire air pressure is important both for vehicle performance and tire life.
C-ABS is a variant of ABS that takes into consideration the lean angle of a two-wheel motorcycle, or the lateral acceleration of a Trike model. The brake pressure required to limit wheel slip when cornering is typically or lower than the pressure required under straight line operation.
C-ELB (Cornering Electronic Linked Braking)
C-ELB takes into account the motorcycle lean angle or Trike lateral acceleration. C-ELB will alter the proportioning of brake pressure between the front and rear brakes when braking while cornering in an attempt to improve the ability of the bike to maintain the rider’s intended path.
C-TCS (Cornering Enhanced Traction Control System)
C-TCS is designed to prevent the rear wheel from excessive spinning under acceleration when going straight or cornering.
C-DSCS (Cornering Drag-Torque Slip Control System)
On bikes equipped with C-DSCS, the system helps keep the rear wheel from slipping or locking up when you quickly downshift or let off the throttle, especially on wet or slippery roads. When turning, it can adjust based on how much a two-wheel bike is leaning or the side-to-side motion on a Trike.
Harley Davidson Road Glide Limited (2024) Color Options
Trim – Black
Color –
Billiard Gray
Vivid Black
Sharkskin Blue
Blue Burst
Red Rock/Vivid Black
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
