DesertX Rally is a high-performance machine, designed to cross desert, rock and forest and satisfy your desire to conquer.
Key Specifications
| Engine Type | Ducati Testastretta 11°, L-Twin cylinders, Desmodromic valvetrain, 4 valves per cylinder, liquid cooled |
| Engine Capacity | 937 cc |
| Max Power | 110 HP / 81 kW @ 9,250 rpm |
| Max Torque | 92 NM / 68 lb-ft @ 6,500 rpm |
| Top Speed | ~ 215 kmph / 133.6 mph |
| Fuel Tank Capacity | 21 L / 5.54 US gallons |
| Weight (Wet/Kerb) | ~ 225 kg / 496 lbs |
| Seat Height | Standard Seat – 910 mm / 35.82 inches Low Seat (accessory) – 880 mm / 34.6 inches |
*n/a – information not provided by manufacturer
All Specifications
Make & Model
| Model | Ducati DesertX Rally |
| Year | 2024 |
Engine
| Engine Type | Ducati Testastretta 11°, L-Twin cylinders, Desmodromic valvetrain, 4 valves per cylinder, liquid cooled |
| Displacement | 937 cc |
| Bore x Stroke | 94 mm x 67.5 mm |
| Compression Ratio | 13.3 : 1 |
| Number of Cylinders | 2 |
| Max Horsepower | 110 HP / 81 kW @ 9,250 rpm |
| Max Torque | 92 NM / 68 lb-ft @ 6,500 rpm |
| Valve Train | DOHC |
| Valves per Cylinder | 4 |
| Engine Management System | Bosch electronic fuel injection system, Ø53 mm throttle bodies with ride-by-wire system |
| Fuel-mixture System | MIKUNI throttle body with full Ride by wire system, diameter: 53 mm (2.09 in), round cross-section. Injectors per cylinder: 1. |
| Lubrication System | lobe-type oil pump with built-in by-pass valve and oil cooler. |
| Cooling System | Water cooling, permanent circulation of coolant by water pump |
| Ignition System | Fully electronic ignition |
| Fuel | Super Unleaded (95-98 RON) |
| Exhaust System | Stainless steel single muffler, catalytic converter and 2 lambda probes |
Performance
| Top Speed | ~ 215 kmph / 133.6 mph |
*n/a – information not provided by manufacturer
Transmission
| Clutch | Hydraulically-controlled slipper/self-servo Wet multiplate clutch |
| Gearbox | 6-speed gearbox with constant mesh gears |
| Primary Drive Ratio | 15/49 |
| Gear Ratios | 1st gear – 14:38 2nd gear – 17:31 3rd gear – 20:28 4th gear – 22:26 5th gear – 23:24 6th gear – 24:23 |
| Final Drive | Regina Chain (525/137ZRDB) |
| Quick Shifter | Ducati Quick Shift (DQS) up/down EVO |
| Traction Control System | Ducati Traction Control |
| Assist & Slipper Clutch | Yes |
Electrical & Electronics System
| Battery | SKYRICH HJT7B-FPZ-SCR 4AH LX5 Lithium battery |
| Alternator/Generator | 14 V – 490 W – 35 A |
| Starter | Electric starter 12 V – 0.7 kW |
| Headlight Type | LED |
| Taillight Type | LED |
| Instrumentation | 5 inch vertical TFT |
| Riding Modes | Sport, Touring, Urban, Wet, Enduro, Rally |
| Traction Control System | Ducati Traction Control |
| ABS | ABS, Cornering ABS |
| Cruise Control | Yes |
Chassis & Suspension
| Frame Type | Tubular steel trellis frame |
| Front Suspension | KYB Ø 48 mm upside-down fork, closed cartridge, compression and rebound adjustable, Kashima Coating on the outer tubes, DLC treatment on the inner tubes |
| Front Suspension Travel | 250 mm / 9.8 inches |
| Rear Suspension | KYB monoshock, Ø 46 mm piston, fully adjustable (high and low speed compression, rebound), remote preload adjustment, aluminum double-sided swingarm |
| Rear Suspension Travel | 240 mm / 9.4 inches |
| Rake | 27.6° |
| Trail | 122 mm / 4.8 inches |
| Rear Subframe | double-sided swinging arm |
| Steering Damper | Non-adjustable Sachs steering damper |
Wheels & Brakes
| Wheels | Takasago Excel rims, carbon steel spokes and lightened billet aluminium hubs. 0.5 kgs lighter than the DesertX wheels |
| Front Wheel/Rim Size | 2.15 ” x 21 “ |
| Front Tire Size | 90/90 – 21 M/C 54V M+S TL (A) |
| Rear Wheel/Rim Size | 4 ” x 18 “ |
| Rear Tire Size | 150/70 R18 M/C 70V M+S TL |
| Front Brakes | 320 mm disc, Semi-floating drilled twin-disc, Brembo Monoblock (M50) with radial connection and 4 pistons, Bosch Cornering ABS |
| Rear Brakes | 265 mm disc, With fixed drilled stainless steel disc, Brembo, 2-piston floating calliper with Bosch Cornering ABS |
Dimension & Weights
| Overall Length | 2398 mm / 94.4 inches |
| Overall Width | 960 mm / 38.98 inches |
| Overall Height | 1445 mm / 56.88 inches |
| Seat Height | Standard Seat – 910 mm / 35.82 inches Low Seat (accessory) – 880 mm / 34.6 inches |
| Wheelbase | 1625 mm / 64 inches |
| Ground Clearance | 280 mm / 11 inches |
| Fuel Tank Capacity | 21 L / 5.54 US gallons |
| Wet (kerb/curb) Weight | ~ 225 kg / 496 lbs |
| Dry Weight | ~ 211 kg / 465.17 lbs |
| Max Load Capacity | 465 kg / 1025.15 lbs |
Riding Aids
- Riding Modes
- Power Modes
- Ducati Wheelie Control (DWC)
- Engine Brake Control (EBC)
- Ducati QuickShifter (up/Down)
- Cruise Control
- Steering Damper
- Self Cancelling Indicators
Ducati DesertX Rally (2024 – ) Color Options
- White & Red
