Experience the ultimate combination of value and performance with the CRF450R-S. Dominate the track with top-notch features, selectable engine modes, and Honda Selectable Torque Control without breaking the bank. And when you beat your friends on pricier bikes, the thrill of victory becomes that much sweeter.
Key Specifications
Engine Type
450cc liquid-cooled single-cylinder four-stroke
Engine Capacity
450 cc / 27.46 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.7 US gallons / 6.43 L
Weight (Wet/Kerb)
247 lbs / 112 kg
Seat Height
37.8 inches / 960 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF450R
Year
2023
Engine Type
450cc liquid-cooled single-cylinder four-stroke
Displacement
450 cc / 27.46 cubic inches
Bore x Stroke
96.0 x 62.1 mm
Compression Ratio
13.5 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
Unicam® SOHC; four valves per cylinder
Valves per Cylinder
4
Ø intake / exhaust valve dia
Ø throttle valve
46mm
Engine Management System
Programmed Fuel-Injection system (PGM-FI)
Fuel-mixture System
Downdraft fuel injection
Lubrication System
Cooling System
Liquid Cooled
Ignition System
Fuel
Exhaust System
Single-muffler exhaust
Emissions Compliance
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Gearbox
Close-ratio five-speed manual
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
#520 Chain; 13T/49T
Quick Shifter
Traction Control System
Honda Selectable Torque Control (HSTC)
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Lithium-ion
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Standard, Smooth, Aggressive
Traction Control System
Honda Selectable Torque Control (HSTC)
Launch Control
HRC launch control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Aluminum twin-spar frame
Front Suspension
49mm inverted Showa® spring fork
Front Suspension Travel
12.2 inches / 310 mm
Rear Suspension
Pro-Link® Showa® single shock
Rear Suspension Travel
12.4 inches / 315 mm
Rake
27.4 °
Trail
4.6 inches / 117 mm
Rear Subframe
Swingarm
Handlebar
Renthal “Fatbar” aluminum
Steering Damper
Wheels & Brakes
Wheels
Black DID DirtStar rims
Front Wheel/Rim Size
21 inch
Front Tire Size
80/100-21 Dunlop MX33
Rear Wheel/Rim Size
19 inch
Rear Tire Size
120/80-19 Dunlop MX33
Front Brakes
Single 260mm disc with twin-piston caliper
Rear Brakes
Single 240mm disc with special rear brake pads
ABS
Dimension & Weights
Overall Length
Overall Width
Overall Height
Seat Height
37.8 inches / 960 mm
Wheelbase
58.4 inches / 1483 mm
Ground Clearance
12.9 inches / 328 mm
Fuel Tank Capacity
1.7 US gallons / 6.43 L
Wet (kerb/curb) Weight
247 lbs / 112 kg
Dry Weight
Max Load Capacity
Features
450cc Unicam® engine
Honda’s Unicam® cylinder head combines single- and double-overhead-cam designs for a compact, lightweight engine with a narrow valve angle. This enhances combustion efficiency, compression ratio, and overall performance.
Downdraft fuel injection
A downdraft intake tract and fuel injector body help increase both power and fuel-metering precision.
Double-spray injector settings
An advanced fuel-injection system sprays twice per intake cycle, delivering optimal fuel atomization for explosive midrange power and impressive overrev performance.
Single-muffler exhaust
The new and improved muffler features a reinforced outer shell and revamped inner pipe construction, all while maintaining its original weight for a perfect balance of strength and performance.
Titanium intake valves
Lightweight titanium intake valves reduce reciprocating mass and permit the use of smaller valve springs, reducing overall engine height.
Compression ratio
A refined squish area helps boost compression to an impressive 13.5:1, improving combustion efficiency for more power.
Central-port cylinder head
The new cylinder head design, highlighted by a centralized oval-shaped exhaust port and paired with the single-muffler exhaust, boosts power above 5000 rpm while optimizing exhaust efficiency.
Aluminum frame
The aluminum twin-spar frame lowers the rear shock, improving the airbox area and lowering the center of gravity. This allows for more holeshots while also enhancing steering and traction.
Showa spring fork
The 49mm Showa fork features a conventional spring design that helps increase the front suspension’s precision and feel, while the revised spring rate provides better bottoming resistance and improved handling.
Low-mount battery box
Putting the batter box low in the chassis helps lower the overall center of gravity, which is always a benefit for responsive handling.
Swingarm
The swingarm uses a special fabrication technique that lets us fine-tune the flex to work with the chassis and give you better rear traction and cornering precision.
Dialed-in suspension settings
Special suspension settings are designed to work with its chassis and engine. You’ll experience excellent overall performance and superior front/rear balance.
260mm front brake
The front brake disc measures 260mm and provides a great feel. The bike also includes front and rear brake-disc guards.
Special rear brake pads
Brakes do more than just stop; they aid in bike setup for turns and jumps. Long-lasting pads offer superior stopping power, a win-win for riders.
Dunlop MX33 tires
Developed using Dunlop’s “block-on-block” design technology, the MX33 tires give excellent feedback and perfectly complement the frame and suspension.
Honda Selectable Torque Control (HSTC)
Easily control your bike’s torque with the handlebar button, activating Honda Selectable Torque Control (HSTC) and allowing you to adjust settings based on available traction.
Engine mode select button
This simple handlebar-mounted button lets you dial in the engine power delivery character with a push of your thumb. You can choose between Standard, Smooth, or Aggressive depending on track conditions.
HRC launch control
Maximize your bike’s power with this specially programmed ECU. Choose the mode, open the throttle, release the clutch, and let HRC launch control do the rest. Get ahead of the competition every time.
Titanium fuel tank
This bike has a lighter, stronger, and thinner titanium fuel tank that maintains the same capacity as our previous plastic unit. It also frees up space and centralizes fuel mass.
Skid plate
A factory skid plate is light and offers the engine and lower-frame protection that the racer demands.
Black rims
Boost your style with sleek black DID DirtStar rims. These lightweight, strong rims undeniably elevate the bike’s aesthetics to new levels of cool.
“In-mold” graphics
With all the time you’ll be spending in the victory circle, you’ll need to look your best. Our “in-mold” graphics look great and stay that way after repeated use.
Flat seat/tank junction
A flat seat/tank junction is part of the superior ergonomics that make moving forward and back on the bike easier, increasing your control.
Renthal “Fatbar”
The aluminum Renthal Fatbar boasts a superior bend that surpasses even the legendary Honda “CR” bar, ensuring a ride you’ll absolutely adore.
Electric starter
No kickstart is needed. Our engineers eliminated it, shedding weight and enhancing performance. Combined with the lithium-ion batteries, the bike achieves perfect balance.
Experience the ultimate combination of value and performance with the CRF450R-S. Dominate the track with top-notch features, selectable engine modes, and Honda Selectable Torque Control without breaking the bank. And when you beat your friends on pricier bikes, the thrill of victory becomes that much sweeter.
Key Specifications
Engine Type
450cc liquid-cooled single-cylinder four-stroke
Engine Capacity
450 cc / 27.46 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.7 US gallons / 6.43 L
Weight (Wet/Kerb)
247 lbs / 112 kg
Seat Height
37.8 inches / 960 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF450R
Year
2024
Engine Type
450cc liquid-cooled single-cylinder four-stroke
Displacement
450 cc / 27.46 cubic inches
Bore x Stroke
96.0 x 62.1 mm
Compression Ratio
13.5 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
Unicam® SOHC; four valves per cylinder
Valves per Cylinder
4
Ø intake / exhaust valve dia
Ø throttle valve
46mm
Engine Management System
Programmed Fuel-Injection system (PGM-FI)
Fuel-mixture System
Downdraft fuel injection
Lubrication System
Cooling System
Liquid Cooled
Ignition System
Fuel
Exhaust System
Single-muffler exhaust
Emissions Compliance
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Gearbox
Close-ratio five-speed manual
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
#520 Chain; 13T/49T
Quick Shifter
Traction Control System
Honda Selectable Torque Control (HSTC)
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Lithium-ion
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Standard, Smooth, Aggressive
Traction Control System
Honda Selectable Torque Control (HSTC)
Launch Control
HRC launch control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Aluminum twin-spar frame
Front Suspension
49mm inverted Showa® spring fork
Front Suspension Travel
12.2 inches / 310 mm
Rear Suspension
Pro-Link® Showa® single shock
Rear Suspension Travel
12.4 inches / 315 mm
Rake
27.1 °
Trail
4.5 inches / 114 mm
Rear Subframe
Swingarm
Handlebar
Renthal “Fatbar” aluminum
Steering Damper
Wheels & Brakes
Wheels
Black DID DirtStar rims
Front Wheel/Rim Size
21 inch
Front Tire Size
80/100-21 Dunlop MX33
Rear Wheel/Rim Size
19 inch
Rear Tire Size
120/80-19 Dunlop MX33
Front Brakes
Single 260mm disc with twin-piston caliper
Rear Brakes
Single 240mm disc with special rear brake pads
ABS
Dimension & Weights
Overall Length
Overall Width
Overall Height
Seat Height
37.8 inches / 960 mm
Wheelbase
58.3 inches / 1481 mm
Ground Clearance
13.2 inches / 335 mm
Fuel Tank Capacity
1.7 US gallons / 6.43 L
Wet (kerb/curb) Weight
247 lbs / 112 kg
Dry Weight
Max Load Capacity
Features
450cc Unicam® engine
Honda’s Unicam® cylinder head combines single- and double-overhead-cam designs for a compact, lightweight engine with a narrow valve angle. This enhances combustion efficiency, compression ratio, and overall performance.
Downdraft fuel injection
A downdraft intake tract and fuel injector body help increase both power and fuel-metering precision.
Double-spray injector settings
An advanced fuel-injection system sprays twice per intake cycle, delivering optimal fuel atomization for explosive midrange power and impressive overrev performance.
Single-muffler exhaust
The new and improved muffler features a reinforced outer shell and revamped inner pipe construction, all while maintaining its original weight for a perfect balance of strength and performance.
Titanium intake valves
Lightweight titanium intake valves reduce reciprocating mass and permit the use of smaller valve springs, reducing overall engine height.
Compression ratio
A refined squish area helps boost compression to an impressive 13.5:1, improving combustion efficiency for more power.
Central-port cylinder head
The new cylinder head design, highlighted by a centralized oval-shaped exhaust port and paired with the single-muffler exhaust, boosts power above 5000 rpm while optimizing exhaust efficiency.
Aluminum frame
The aluminum twin-spar frame lowers the rear shock, improving the airbox area and lowering the center of gravity. This allows for more holeshots while also enhancing steering and traction.
Showa spring fork
The 49mm Showa fork features a conventional spring design that helps increase the front suspension’s precision and feel, while the revised spring rate provides better bottoming resistance and improved handling.
Low-mount battery box
Putting the batter box low in the chassis helps lower the overall center of gravity, which is always a benefit for responsive handling.
Swingarm
The swingarm uses a special fabrication technique that lets us fine-tune the flex to work with the chassis and give you better rear traction and cornering precision.
Dialed-in suspension settings
Special suspension settings are designed to work with its chassis and engine. You’ll experience excellent overall performance and superior front/rear balance.
260mm front brake
The front brake disc measures 260mm and provides a great feel. The bike also includes front and rear brake-disc guards.
Special rear brake pads
Brakes do more than just stop; they aid in bike setup for turns and jumps. Long-lasting pads offer superior stopping power, a win-win for riders.
Dunlop MX33 tires
Developed using Dunlop’s “block-on-block” design technology, the MX33 tires give excellent feedback and perfectly complement the frame and suspension.
Honda Selectable Torque Control (HSTC)
Easily control your bike’s torque with the handlebar button, activating Honda Selectable Torque Control (HSTC) and allowing you to adjust settings based on available traction.
Engine mode select button
This simple handlebar-mounted button lets you dial in the engine power delivery character with a push of your thumb. You can choose between Standard, Smooth, or Aggressive depending on track conditions.
HRC launch control
Maximize your bike’s power with this specially programmed ECU. Choose the mode, open the throttle, release the clutch, and let HRC launch control do the rest. Get ahead of the competition every time.
Titanium fuel tank
This bike has a lighter, stronger, and thinner titanium fuel tank that maintains the same capacity as our previous plastic unit. It also frees up space and centralizes fuel mass.
Skid plate
A factory skid plate is light and offers the engine and lower-frame protection that the racer demands.
Black rims
Boost your style with sleek black DID DirtStar rims. These lightweight, strong rims undeniably elevate the bike’s aesthetics to new levels of cool.
“In-mold” graphics
With all the time you’ll be spending in the victory circle, you’ll need to look your best. Our “in-mold” graphics look great and stay that way after repeated use.
Flat seat/tank junction
A flat seat/tank junction is part of the superior ergonomics that make moving forward and back on the bike easier, increasing your control.
Renthal “Fatbar”
The aluminum Renthal Fatbar boasts a superior bend that surpasses even the legendary Honda “CR” bar, ensuring a ride you’ll absolutely adore.
Electric starter
No kickstart is needed. Our engineers eliminated it, shedding weight and enhancing performance. Combined with the lithium-ion batteries, the bike achieves perfect balance.
Whether starting out or stepping up, the CRF110F is perfect for young riders. With a smooth four-stroke engine, electric start, fuel injection, and an auto-clutch transmission, it’s easy to operate and builds confidence fast. Rugged, reliable, and ready for anything—this bike turns trail time into big-time fun.
Key Specifications
Engine Type
109cc air-cooled single-cylinder four-stroke
Engine Capacity
109 cc / 6.65 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.20 US gallons / 4.55 L
Weight (Wet/Kerb)
169 lbs / 77 kg
Seat Height
25.9 inches / 657 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF110F
Year
2026
Engine Type
Air-cooled single-cylinder four-stroke
Displacement
109 cc / 6.65 cubic inches
Bore x Stroke
50.0 x 55.6 mm
Compression Ratio
9.0 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
SOHC; two valves per cylinder
Valves per Cylinder
2
Ø intake / exhaust valve dia
Ø throttle valve
19mm
Engine Management System
Programmed Fuel Injection system (PGM-FI)
Fuel-mixture System
Fuel-injection, 19mm throttle bore
Lubrication System
Cooling System
Air Cooled
Ignition System
Full Transistorized
Fuel
Exhaust System
Emissions Compliance
Meets California Air Resources Board (CARB) and EPA off-road emissions standards.
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Automatic
Gearbox
Four-speed with automatic clutch
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
#420 Chain; 14T/38T
Quick Shifter
Traction Control System
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Traction Control System
Launch Control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Front Suspension
31mm telescopic fork; 10cm of travel
Front Suspension Travel
4.3 inches / 109 mm
Rear Suspension
Single-shock; 9.5cm of travel
Rear Suspension Travel
3.8 inches / 97 mm
Rake
25°10′ / 25.4°
Trail
2.0 inches / 53 mm
Rear Subframe
Swingarm
Handlebar
Steering Damper
Wheels & Brakes
Wheels
Front Wheel/Rim Size
14 inch
Front Tire Size
70/100-14
Rear Wheel/Rim Size
12 inch
Rear Tire Size
80/100-12
Front Brakes
95mm Drum
Rear Brakes
95mm Drum
ABS
Dimension & Weights
Overall Length
Overall Width
Overall Height
Seat Height
25.9 inches / 657 mm
Wheelbase
41.9 inches / 1065 mm
Ground Clearance
6.7 inches / 170 mm
Fuel Tank Capacity
1.20 US gallons / 4.55 L
Wet (kerb/curb) Weight
169 lbs / 77 kg
Dry Weight
169 lbs / 77 kg
Max Load Capacity
Features
Four-stroke engine
The Honda four-stroke single-cylinder engine provides smooth and reliable performance, making it ideal for a broad range of riders, including beginners.
Fuel injection
Fuel injection ensures easy startup in cold weather, reduces emissions and improves performance and fuel efficiency compared to carbureted bikes.
Ample suspension travel
This entry-level dirt bike offers ample suspension travel at the front and rear, ensuring a comfortable and smooth ride.
Steel frame and swingarm
Less experienced riders can be hard on equipment, especially when starting out. That’s why we equipped the bike with a strong twin-spar steel frame and swingarm that can handle the rigors of off-road riding.
Adjustable speed limiter
Turn a screw to set the top speed and match the power to the rider’s skill level, preventing new riders from going too fast too soon.
Automatic clutch
For new riders, there is no clutch lever to master, so there’s no chance of stalling. Simply shift with your foot, as the smooth transmission offers four gear ratios.
Backup kickstarter
Even if your bike has a dead battery, you still can get going with the backup kickstarter. It’s easy for you to use and helps ensure your fun day doesn’t stop.
Clean-running engine
The engine runs cleanly by fitting the bike with fuel injection and meets California’s stringent CARB emissions standards for off-road motorcycles.
Tough bodywork
Riders can be harsh on equipment and taking a spill is a natural part of learning. Its plastic fenders, tank, and body parts resemble our larger CRF motocross bikes, and can easily withstand minor dings and scratches.
Low seat height
It’s important to ensure that the size of the bike is appropriate for the rider. A low seat height can help build confidence from the start. This bike is perfectly positioned between the CRF50F and CRF125F.
Half-waffle grips
Just like the pros, this bike comes with half-waffle pattern grips, a typical Honda detail that displays our dedication to all models.
Keyed ignition
You decide who rides and when because you hold the keys. Got your homework done? Good—let’s ride!
Electric starter
Push a button and go—that’s how easy it is to get going. Starting the engine after a tip-over is easy, and the push button prevents frustration in case of an accidental engine stop.
With user-friendly power, legendary Honda reliability, and big bike-style manual clutch, the CRF125F is ready for riders on the rise. Available in both standard and Big Wheel trims, it features fuel injection, electric start, and a durable four-stroke engine—perfect for stepping up or anyone ready to hit the trail and never look back.
Key Specifications
Engine Type
125cc air-cooled single-cylinder four-stroke
Engine Capacity
124.9 cc / 7.62 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.20 US gallons / 4.54 L
Weight (Wet/Kerb)
194 lbs / 88 kg
Seat Height
Standard – 29.1 inches / 739 mm Big Wheel – 30.9 inches / 785 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF125F
Year
2023
Engine
Engine Type
Air-cooled single-cylinder four-stroke
Displacement
124.9 cc / 7.62 cubic inches
Bore x Stroke
52.4 x 57.9 mm
Compression Ratio
9.0 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
SOHC; two valves per cylinder
Valves per Cylinder
2
Ø intake / exhaust valve dia
Ø throttle valve
22mm
Engine Management System
Programmed Fuel Injection system (PGM-FI)
Fuel-mixture System
Fuel-injection, 22mm throttle bore
Lubrication System
Cooling System
Air Cooled
Ignition System
Full Transistorized
Fuel
Exhaust System
Emissions Compliance
Meets CARB and EPA off-road emissions standards
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Gearbox
Four-speed
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
Chain; 13T/46T
Quick Shifter
Traction Control System
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Traction Control System
Launch Control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Front Suspension
31mm telescopic fork; 5.9 inches / 150mm travel
Front Suspension Travel
Standard – 5.1 inches / 130mm Big Wheel – 6.3 inches / 160mm
Rear Suspension
Pro-Link® single-shock
Rear Suspension Travel
Standard – 5.5 inches / 140mm Big Wheel – 6.3 inches / 160mm
Rake (Caster Angle)
27°30′ / 27.5°
Trail
Standard – 3.19 inches / 81mm Big Wheel – 3.70 inches / 94mm
Rear Subframe
Swingarm
Handlebar
Steering Damper
Wheels & Brakes
Wheels
Wire Spoked RIms
Front Wheel/Rim Size
Standard – 17 inch Big Wheel – 19 inch
Front Tire Size
Standard – 70/100-17 Big Wheel – 10/100-19
Rear Wheel/Rim Size
Standard – 14 inch Big Wheel – 16 inch
Rear Tire Size
Standard – 90/100-14 Big Wheel – 90/100-16
Front Brakes
Single 220mm hydraulic disc
Rear Brakes
95mm Drum
ABS
Dimension & Weights
Overall Length
Overall Width
Overall Height
Seat Height
Standard – 29.1 inches / 739 mm Big Wheel – 30.9 inches / 785 mm
Wheelbase
48.0 inches / 1220 mm
Ground Clearance
8.3 inches / 210 mm
Fuel Tank Capacity
1.20 US gallons / 4.54 L
Wet (kerb/curb) Weight
Standard – 194 lbs / 88 kg Big Wheel – 199 lbs / 90.27 kg
Dry Weight
Standard – 194 lbs / 87.99 kg Big Wheel – 199 lbs / 90.27 kg
Max Load Capacity
Features
Reliable engine
The 125cc single-cylinder four-stroke engine has a broad powerband and offers dependable performance for beginners. Fuel injection enhances its efficiency.
Fuel injection
Fuel injection means it starts right up, even in cold weather. Compared to a carbureted bike, it also helps reduce emissions and enhance performance and fuel efficiency.
Steel frame and swingarm
We designed these bikes with strong, twin-spar-type steel frames and swingarms that can handle the bumps and dings of off-road riding.
Pro-Link® rear suspension
Our Pro-Link® progressive suspension connects a single heavy-duty shock to the swingarm, delivering an excellent combination over a wide range of riding conditions.
Front disc brake
The front disc brake provides superior stopping power, and the front disc rotor is drilled for lightness and better wet-weather performance.
Proven manual clutch
The heavy-duty traditional manual clutch is durable and helps promote smooth shifting.
Four-speed transmission
The four-speed gearbox is identical to a full-sized off-road motorcycle, providing complete control.
Sealed battery
A maintenance-free sealed battery helps ensure that the bike is ready to ride whenever you are.
Clean-running engine
Another benefit of fitting it with fuel injection? It meets California’s stringent CARB emissions standards for off-road motorcycles.
Stylish and tough bodywork
This bike can handle the hard knocks of learning riders. The tough plastic fenders, tank, and other body parts are inspired by our CRF motocross bikes and engineered to shrug off minor dings.
Big Wheel version
Looking for something a little larger? Check out our Big Wheel trim—the same great bike but a better fit for taller riders with its larger wheels giving it a higher seat height and an additional two inches of ground clearance.
Half-waffle grips
Just like the pros use, this bike gets half-waffle pattern grips. Might as well start off right!
Low seat height
It’s important to have a bike sized right for your rider. The standard model features a low 29.1-inch seat height, which helps build confidence right from the start.
Electric starter
The push-button starter is designed to add minimal weight and make starting easier in all conditions.
Keyed ignition switch
A keyed ignition switch allows you to control who can ride the vehicle, which is especially important if younger riders are in the home.
With user-friendly power, legendary Honda reliability, and big bike-style manual clutch, the CRF125F is ready for riders on the rise. Available in both standard and Big Wheel trims, it features fuel injection, electric start, and a durable four-stroke engine—perfect for stepping up or anyone ready to hit the trail and never look back.
Key Specifications
Engine Type
125cc air-cooled single-cylinder four-stroke
Engine Capacity
124.9 cc / 7.62 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.20 US gallons / 4.54 L
Weight (Wet/Kerb)
194 lbs / 88 kg
Seat Height
Standard – 29.1 inches / 739 mm Big Wheel – 30.9 inches / 785 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF125F
Year
2025
Engine
Engine Type
Air-cooled single-cylinder four-stroke
Displacement
124.9 cc / 7.62 cubic inches
Bore x Stroke
52.4 x 57.9 mm
Compression Ratio
9.0 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
SOHC; two valves per cylinder
Valves per Cylinder
2
Ø intake / exhaust valve dia
Ø throttle valve
22mm
Engine Management System
Programmed Fuel Injection system (PGM-FI)
Fuel-mixture System
Fuel-injection, 22mm throttle bore
Lubrication System
Cooling System
Air Cooled
Ignition System
Full Transistorized
Fuel
Exhaust System
Emissions Compliance
Meets CARB and EPA off-road emissions standards
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Gearbox
Four-speed
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
Chain; 13T/46T
Quick Shifter
Traction Control System
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Traction Control System
Launch Control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Front Suspension
31mm telescopic fork; 5.9 inches / 150mm travel
Front Suspension Travel
Standard – 5.1 inches / 130mm Big Wheel – 6.3 inches / 160mm
Rear Suspension
Pro-Link® single-shock
Rear Suspension Travel
Standard – 5.5 inches / 140mm Big Wheel – 6.3 inches / 160mm
Rake (Caster Angle)
27°30′ / 27.5°
Trail
Standard – 3.19 inches / 81mm Big Wheel – 3.70 inches / 94mm
Rear Subframe
Swingarm
Handlebar
Steering Damper
Wheels & Brakes
Wheels
Wire Spoked RIms
Front Wheel/Rim Size
Standard – 17 inch Big Wheel – 19 inch
Front Tire Size
Standard – 70/100-17 Big Wheel – 10/100-19
Rear Wheel/Rim Size
Standard – 14 inch Big Wheel – 16 inch
Rear Tire Size
Standard – 90/100-14 Big Wheel – 90/100-16
Front Brakes
Single 220mm hydraulic disc
Rear Brakes
95mm Drum
ABS
Dimension & Weights
Overall Length
Overall Width
Overall Height
Seat Height
Standard – 29.1 inches / 739 mm Big Wheel – 30.9 inches / 785 mm
Wheelbase
48.0 inches / 1220 mm
Ground Clearance
8.3 inches / 210 mm
Fuel Tank Capacity
1.20 US gallons / 4.54 L
Wet (kerb/curb) Weight
Standard – 194 lbs / 88 kg Big Wheel – 199 lbs / 90.27 kg
Dry Weight
Standard – 194 lbs / 87.99 kg Big Wheel – 199 lbs / 90.27 kg
Max Load Capacity
Features
Reliable engine
The 125cc single-cylinder four-stroke engine has a broad powerband and offers dependable performance for beginners. Fuel injection enhances its efficiency.
Fuel injection
Fuel injection means it starts right up, even in cold weather. Compared to a carbureted bike, it also helps reduce emissions and enhance performance and fuel efficiency.
Steel frame and swingarm
We designed these bikes with strong, twin-spar-type steel frames and swingarms that can handle the bumps and dings of off-road riding.
Pro-Link® rear suspension
Our Pro-Link® progressive suspension connects a single heavy-duty shock to the swingarm, delivering an excellent combination over a wide range of riding conditions.
Front disc brake
The front disc brake provides superior stopping power, and the front disc rotor is drilled for lightness and better wet-weather performance.
Proven manual clutch
The heavy-duty traditional manual clutch is durable and helps promote smooth shifting.
Four-speed transmission
The four-speed gearbox is identical to a full-sized off-road motorcycle, providing complete control.
Sealed battery
A maintenance-free sealed battery helps ensure that the bike is ready to ride whenever you are.
Clean-running engine
Another benefit of fitting it with fuel injection? It meets California’s stringent CARB emissions standards for off-road motorcycles.
Stylish and tough bodywork
This bike can handle the hard knocks of learning riders. The tough plastic fenders, tank, and other body parts are inspired by our CRF motocross bikes and engineered to shrug off minor dings.
Big Wheel version
Looking for something a little larger? Check out our Big Wheel trim—the same great bike but a better fit for taller riders with its larger wheels giving it a higher seat height and an additional two inches of ground clearance.
Half-waffle grips
Just like the pros use, this bike gets half-waffle pattern grips. Might as well start off right!
Low seat height
It’s important to have a bike sized right for your rider. The standard model features a low 29.1-inch seat height, which helps build confidence right from the start.
Electric starter
The push-button starter is designed to add minimal weight and make starting easier in all conditions.
Keyed ignition switch
A keyed ignition switch allows you to control who can ride the vehicle, which is especially important if younger riders are in the home.
With user-friendly power, legendary Honda reliability, and big bike-style manual clutch, the CRF125F is ready for riders on the rise. Available in both standard and Big Wheel trims, it features fuel injection, electric start, and a durable four-stroke engine—perfect for stepping up or anyone ready to hit the trail and never look back.
Key Specifications
Engine Type
125cc air-cooled single-cylinder four-stroke
Engine Capacity
124.9 cc / 7.62 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.20 US gallons / 4.54 L
Weight (Wet/Kerb)
194 lbs / 88 kg
Seat Height
Standard – 29.1 inches / 739 mm Big Wheel – 30.9 inches / 785 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF125F
Year
2026
Engine
Engine Type
Air-cooled single-cylinder four-stroke
Displacement
124.9 cc / 7.62 cubic inches
Bore x Stroke
52.4 x 57.9 mm
Compression Ratio
9.0 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
SOHC; two valves per cylinder
Valves per Cylinder
2
Ø intake / exhaust valve dia
Ø throttle valve
22mm
Engine Management System
Programmed Fuel Injection system (PGM-FI)
Fuel-mixture System
Fuel-injection, 22mm throttle bore
Lubrication System
Cooling System
Air Cooled
Ignition System
Full Transistorized
Fuel
Exhaust System
Emissions Compliance
Meets CARB and EPA off-road emissions standards
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Gearbox
Four-speed
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
Chain; 13T/46T
Quick Shifter
Traction Control System
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Traction Control System
Launch Control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Front Suspension
31mm telescopic fork; 5.9 inches / 150mm travel
Front Suspension Travel
Standard – 5.1 inches / 130mm Big Wheel – 6.3 inches / 160mm
Rear Suspension
Pro-Link® single-shock
Rear Suspension Travel
Standard – 5.5 inches / 140mm Big Wheel – 6.3 inches / 160mm
Rake (Caster Angle)
27°30′ / 27.5°
Trail
Standard – 3.19 inches / 81mm Big Wheel – 3.70 inches / 94mm
Rear Subframe
Swingarm
Handlebar
Steering Damper
Wheels & Brakes
Wheels
Wire Spoked RIms
Front Wheel/Rim Size
Standard – 17 inch Big Wheel – 19 inch
Front Tire Size
Standard – 70/100-17 Big Wheel – 10/100-19
Rear Wheel/Rim Size
Standard – 14 inch Big Wheel – 16 inch
Rear Tire Size
Standard – 90/100-14 Big Wheel – 90/100-16
Front Brakes
Single 220mm hydraulic disc
Rear Brakes
95mm Drum
ABS
Dimension & Weights
Overall Length
Overall Width
Overall Height
Seat Height
Standard – 29.1 inches / 739 mm Big Wheel – 30.9 inches / 785 mm
Wheelbase
48.0 inches / 1220 mm
Ground Clearance
8.3 inches / 210 mm
Fuel Tank Capacity
1.20 US gallons / 4.54 L
Wet (kerb/curb) Weight
Standard – 194 lbs / 88 kg Big Wheel – 199 lbs / 90.27 kg
Dry Weight
Standard – 194 lbs / 87.99 kg Big Wheel – 199 lbs / 90.27 kg
Max Load Capacity
Features
Reliable engine
The 125cc single-cylinder four-stroke engine has a broad powerband and offers dependable performance for beginners. Fuel injection enhances its efficiency.
Fuel injection
Fuel injection means it starts right up, even in cold weather. Compared to a carbureted bike, it also helps reduce emissions and enhance performance and fuel efficiency.
Steel frame and swingarm
We designed these bikes with strong, twin-spar-type steel frames and swingarms that can handle the bumps and dings of off-road riding.
Pro-Link® rear suspension
Our Pro-Link® progressive suspension connects a single heavy-duty shock to the swingarm, delivering an excellent combination over a wide range of riding conditions.
Front disc brake
The front disc brake provides superior stopping power, and the front disc rotor is drilled for lightness and better wet-weather performance.
Proven manual clutch
The heavy-duty traditional manual clutch is durable and helps promote smooth shifting.
Four-speed transmission
The four-speed gearbox is identical to a full-sized off-road motorcycle, providing complete control.
Sealed battery
A maintenance-free sealed battery helps ensure that the bike is ready to ride whenever you are.
Clean-running engine
Another benefit of fitting it with fuel injection? It meets California’s stringent CARB emissions standards for off-road motorcycles.
Stylish and tough bodywork
This bike can handle the hard knocks of learning riders. The tough plastic fenders, tank, and other body parts are inspired by our CRF motocross bikes and engineered to shrug off minor dings.
Big Wheel version
Looking for something a little larger? Check out our Big Wheel trim—the same great bike but a better fit for taller riders with its larger wheels giving it a higher seat height and an additional two inches of ground clearance.
Half-waffle grips
Just like the pros use, this bike gets half-waffle pattern grips. Might as well start off right!
Low seat height
It’s important to have a bike sized right for your rider. The standard model features a low 29.1-inch seat height, which helps build confidence right from the start.
Electric starter
The push-button starter is designed to add minimal weight and make starting easier in all conditions.
Keyed ignition switch
A keyed ignition switch allows you to control who can ride the vehicle, which is especially important if younger riders are in the home.
Born in Baja. Built for everywhere else. The CRF450R delivers championship-level off-road performance with trail-tuned precision and proven durability. With its six-speed gearbox, 19-inch rear wheel, it’s ready for everything from desert races to tight singletrack. If the trail doesn’t quit, neither will you.
Key Specifications
Engine Type
Liquid-cooled 4-stroke single cylinder uni-cam
Engine Capacity
449.7 cc / 27.4 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.66 US gallons / 6.3 L
Weight (Wet/Kerb)
243.8 lbs / 110.6 kg
Seat Height
37.8 inches / 961 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF450R
Year
2026
Engine Type
Liquid-cooled 4-stroke single cylinder uni-cam
Displacement
449.7 cc / 27.4 cubic inches
Bore x Stroke
96.0 x 62.1 mm
Compression Ratio
13.5 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
Unicam® SOHC
Valves per Cylinder
n/a
Ø intake / exhaust valve dia
Ø throttle valve
Engine Management System
CDI Electronic Fuel injection (PGM-FI)
Fuel-mixture System
Lubrication System
Cooling System
Liquid Cooled
Ignition System
CDI
Fuel
Exhaust System
Emissions Compliance
Engine
Oil Capacity
1.25 Litres / 0.33 US gallons
Starter
Electric
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet type multi-plate
Gearbox
Constant mesh
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
Chain
Quick Shifter
Traction Control System
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Traction Control System
Launch Control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Aluminium twin tube
Front Suspension
Showa 49mm USD fork
Front Suspension Travel
12.2 inches / 310 mm
Rear Suspension
Showa monoshock using Honda Pro-Link
Rear Suspension Travel
12.2 inches / 310 mm
Rake (Caster Angle)
27°19′ / 27.3°
Trail
4.53 inches / 115 mm
Rear Subframe
Swingarm
Handlebar
Steering Damper
Wheels & Brakes
Wheels
Aluminium spoke
Front Wheel/Rim Size
21 inch
Front Tire Size
80/100-21-51M Dunlop MX33F
Rear Wheel/Rim Size
19 inch
Rear Tire Size
120/80-19-63M Dunlop MX33
Front Brakes
Single 260mm disk
Rear Brakes
Single 240mm disk
ABS
Dimension & Weights
Overall Length
86.0 inches / 2183 mm
Overall Width
32.6 inches / 827 mm
Overall Height
49.8 inches / 1265 mm
Seat Height
37.8 inches / 961 mm
Wheelbase
58.3 inches / 1482 mm
Ground Clearance
13.1 inches / 333 mm
Fuel Tank Capacity
1.66 US gallons / 6.3 L
Wet (kerb/curb) Weight
243.8 lbs / 110.6 kg
Dry Weight
238.1 lbs / 108 kg
Max Load Capacity
Features
450cc Unicam® engine
Honda’s Unicam® design creates a compact engine that saves weight. The included valve angle flattens the combustion chamber for easier ignition while the camshaft sits lower, making it more compact and lowering the center of gravity.
Fuel injection
Our proven fuel injection system provides excellent torque, spot-on metering, and response, especially in the critical low-rpm range. Additionally, it automatically compensates for changes in elevation and weather.
Titanium intake and exhaust valves
Lightweight titanium intake and exhaust valves permit smaller valve springs, reducing overall engine height.
Twin-spar chassis
A lightweight, stiff, twin-spar aluminum chassis provides excellent handling while being wider than the standard MX frame to fit the six-speed transmission.
Dunlop MX52 tires
Dunlop’s MX52 tires provide excellent traction across various terrains and conditions, making them critical for on- and off-road bikes.
Low center of gravity
The Unicam® engine’s compact design and our center-of-mass engineering reduce the bike’s weight and improve handling.
Works-style front brake
Increased stopping power and handling are thanks to the compact twin-piston front brake caliper, anodized aluminum brake pistons, and lightweight 260mm front disc that minimize unsprung weight.
Works-style rear brake
An HRC works-style rear brake system uses a 240mm brake rotor that integrates with the rear master cylinder and fluid reservoir, eliminating the need for a separate reservoir and hose.
18-inch rear wheel
The 18-inch rear wheel provides a great selection of off-road tires, and the black DID rims add to the aesthetic appeal.
Wide-ratio six-speed transmission
Having six speeds in the transmission, as opposed to a typical five on an MX bike, provides more versatility. This bike can handle everything from East Coast rock crawling to wide-open Baja blasts.
Tuned-weight crank
The bike has a unique crankshaft that differs from our MX and dual-sport models. The crankshaft’s weight and inertial characteristics play a big role in power delivery.
Dual radiators
The dual radiators feature a refined core for superior heat dissipation. At the same time, the coolant recovery tank is in front of the engine between the frame downtubes for an improved center of gravity.
Oversized fuel tank
We gave the X model a larger, 2.0-gallon resin fuel tank. This will allow for fewer fuel stops, which can save valuable time over the course of a long ride or race.
Skid plate
The factory skid plate is light, yet it also offers the engine and lower-frame protection that serious riders demand on a machine like this.
Factory handguards
Designed exclusively for off-road riders and manufactured to Honda standards, these guards protect against rocks, branches, thorns, and brushes while giving the bike a polished look.
Works MX styling
If the X-model graphics remind you of our MX bikes, that’s because they’re derived from them. The smooth bodywork makes it easy to move around, while the in-mold graphics are durable, too.
Gear-driver counterbalancer
The gear-driven counterbalancer reduces vibration and drives the water pump.
California Green-Sticker compliant
California riders can ride this bike off-road year-round in any open OHV area since it is Green-Sticker compliant.
Superior ergonomics
Placing the rider’s legs at the narrowest part of the frame helps improve comfort and handling.
Sidestand
A sidestand may seem insignificant, but this forged alloy piece is an exceptional example of this bike’s attention to detail.
Fuel mileage meter
The fuel mileage meter is a key feature that displays current and average fuel mileage and fuel consumption and can show data in miles or kilometers. It’s in the same digital display as the speedometer, odometer, tripmeter, and clock.
Electric start
The electric start system ensures trouble-free starting. It drives the clutch side of the crankshaft, providing superior lubrication to starter gears while allowing a narrow engine with a short, strong crank.
Lighting package
It has a complete lighting package (headlight and taillight) for improved visibility in low-light conditions.
Born in Baja. Built for everywhere else. The CRF450R delivers championship-level off-road performance with trail-tuned precision and proven durability. With its six-speed gearbox, 19-inch rear wheel, it’s ready for everything from desert races to tight singletrack. If the trail doesn’t quit, neither will you.
Key Specifications
Engine Type
Liquid-cooled 4-stroke single cylinder uni-cam
Engine Capacity
449.7 cc / 27.4 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.66 US gallons / 6.3 L
Weight (Wet/Kerb)
243.8 lbs / 110.6 kg
Seat Height
37.8 inches / 961 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF450RWE
Year
2026
Engine Type
Liquid-cooled 4-stroke single cylinder uni-cam
Displacement
449.7 cc / 27.4 cubic inches
Bore x Stroke
96.0 x 62.1 mm
Compression Ratio
13.5 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
Unicam® SOHC
Valves per Cylinder
n/a
Ø intake / exhaust valve dia
Ø throttle valve
Engine Management System
CDI Electronic Fuel injection (PGM-FI)
Fuel-mixture System
Lubrication System
Cooling System
Liquid Cooled
Ignition System
CDI
Fuel
Exhaust System
Emissions Compliance
Engine
Oil Capacity
1.25 Litres / 0.33 US gallons
Starter
Electric
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet type multi-plate
Gearbox
Constant mesh
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
Chain
Quick Shifter
Traction Control System
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Traction Control System
Launch Control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Aluminium twin tube
Front Suspension
Showa 49mm USD fork
Front Suspension Travel
12.2 inches / 310 mm
Rear Suspension
Showa monoshock using Honda Pro-Link
Rear Suspension Travel
12.4 inches / 315 mm
Rake (Caster Angle)
27°19′ / 27.3°
Trail
4.53 inches / 115 mm
Rear Subframe
Swingarm
Handlebar
Steering Damper
Wheels & Brakes
Wheels
Aluminium spoke
Front Wheel/Rim Size
21 inch
Front Tire Size
80/100-21-51M Dunlop MX33F
Rear Wheel/Rim Size
19 inch
Rear Tire Size
120/80-19-63M Dunlop MX33
Front Brakes
Single 260mm disk
Rear Brakes
Single 240mm disk
ABS
Dimension & Weights
Overall Length
86.0 inches / 2183 mm
Overall Width
32.6 inches / 827 mm
Overall Height
49.8 inches / 1265 mm
Seat Height
37.8 inches / 961 mm
Wheelbase
58.3 inches / 1482 mm
Ground Clearance
13.1 inches / 333 mm
Fuel Tank Capacity
1.66 US gallons / 6.3 L
Wet (kerb/curb) Weight
243.8 lbs / 110.6 kg
Dry Weight
238.1 lbs / 108 kg
Max Load Capacity
Features
450cc Unicam® engine
Honda’s Unicam® design creates a compact engine that saves weight. The included valve angle flattens the combustion chamber for easier ignition while the camshaft sits lower, making it more compact and lowering the center of gravity.
Fuel injection
Our proven fuel injection system provides excellent torque, spot-on metering, and response, especially in the critical low-rpm range. Additionally, it automatically compensates for changes in elevation and weather.
Titanium intake and exhaust valves
Lightweight titanium intake and exhaust valves permit smaller valve springs, reducing overall engine height.
Twin-spar chassis
A lightweight, stiff, twin-spar aluminum chassis provides excellent handling while being wider than the standard MX frame to fit the six-speed transmission.
Dunlop MX52 tires
Dunlop’s MX52 tires provide excellent traction across various terrains and conditions, making them critical for on- and off-road bikes.
Low center of gravity
The Unicam® engine’s compact design and our center-of-mass engineering reduce the bike’s weight and improve handling.
Works-style front brake
Increased stopping power and handling are thanks to the compact twin-piston front brake caliper, anodized aluminum brake pistons, and lightweight 260mm front disc that minimize unsprung weight.
Works-style rear brake
An HRC works-style rear brake system uses a 240mm brake rotor that integrates with the rear master cylinder and fluid reservoir, eliminating the need for a separate reservoir and hose.
18-inch rear wheel
The 18-inch rear wheel provides a great selection of off-road tires, and the black DID rims add to the aesthetic appeal.
Wide-ratio six-speed transmission
Having six speeds in the transmission, as opposed to a typical five on an MX bike, provides more versatility. This bike can handle everything from East Coast rock crawling to wide-open Baja blasts.
Tuned-weight crank
The bike has a unique crankshaft that differs from our MX and dual-sport models. The crankshaft’s weight and inertial characteristics play a big role in power delivery.
Dual radiators
The dual radiators feature a refined core for superior heat dissipation. At the same time, the coolant recovery tank is in front of the engine between the frame downtubes for an improved center of gravity.
Oversized fuel tank
We gave the X model a larger, 2.0-gallon resin fuel tank. This will allow for fewer fuel stops, which can save valuable time over the course of a long ride or race.
Skid plate
The factory skid plate is light, yet it also offers the engine and lower-frame protection that serious riders demand on a machine like this.
Factory handguards
Designed exclusively for off-road riders and manufactured to Honda standards, these guards protect against rocks, branches, thorns, and brushes while giving the bike a polished look.
Works MX styling
If the X-model graphics remind you of our MX bikes, that’s because they’re derived from them. The smooth bodywork makes it easy to move around, while the in-mold graphics are durable, too.
Gear-driver counterbalancer
The gear-driven counterbalancer reduces vibration and drives the water pump.
California Green-Sticker compliant
California riders can ride this bike off-road year-round in any open OHV area since it is Green-Sticker compliant.
Superior ergonomics
Placing the rider’s legs at the narrowest part of the frame helps improve comfort and handling.
Sidestand
A sidestand may seem insignificant, but this forged alloy piece is an exceptional example of this bike’s attention to detail.
Fuel mileage meter
The fuel mileage meter is a key feature that displays current and average fuel mileage and fuel consumption and can show data in miles or kilometers. It’s in the same digital display as the speedometer, odometer, tripmeter, and clock.
Electric start
The electric start system ensures trouble-free starting. It drives the clutch side of the crankshaft, providing superior lubrication to starter gears while allowing a narrow engine with a short, strong crank.
Lighting package
It has a complete lighting package (headlight and taillight) for improved visibility in low-light conditions.
The CRF150R uses performance technology based on our championship winning CRF450R and CRF250R. And this bike handles. Only one step below its bigger brothers, the CRF150R carves corners, rides ruts and catches air like only a CRF-R can. The strong, slim and lightweight steel tube frame mounts a low-friction, long-travel, fully adjustable inverted front fork – just like its big brothers. With performance DNA this strong, you’ll be winning races in no time. The 25YM CRF150R receives a new graphic upgrade to bring it in line with its larger family members, the CRF250R and CRF450R.
Key Specifications
Engine Type
Liquid-Cooled 4-Stroke 4-Valve Unicam Single
Engine Capacity
149.7 cc / 9.14 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.14 US gallons / 4.3 L
Weight (Wet/Kerb)
186.1 lbs / 84.4 kg
Seat Height
34.1 inches / 866 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF150R
Year
2025
Engine Type
Liquid-Cooled 4-Stroke 4-Valve Unicam Single
Displacement
149.7 cc / 9.14 cubic inches
Bore x Stroke
66.0 x 43.8 mm
Compression Ratio
11.7 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
Unicam® SOHC
Valves per Cylinder
4
Ø intake / exhaust valve dia
Ø throttle valve
32mm
Engine Management System
32mm Keihin FCR flat slide carburettor with throttle position sensor (TPS)
Fuel-mixture System
Carburettor
Lubrication System
Cooling System
Liquid Cooled
Ignition System
Solid-state Capacitor Discharge (CDI) with electronic advance
Fuel
Exhaust System
Emissions Compliance
Engine
Starter
Kick
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multiplate
Gearbox
Close-Ratio 5-speed
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
Roller Chain, 15T/50T
Quick Shifter
Traction Control System
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Alternator/Generator
Starter
Kick
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Traction Control System
Launch Control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Semi-double; Steel tube
Front Suspension
37mm inverted Showa leading-axle telescopic fork with adjustable compression and rebound damping
Front Suspension Travel
10.8 inches / 275 mm
Rear Suspension
Pro-Link with single Showa damper, adjustable compression and rebound damping
Rear Suspension Travel
11.1 inches / 282 mm
Rake
27 °
Trail
3.78 inches / 96 mm
Rear Subframe
Swingarm
Handlebar
Steering Damper
Wheels & Brakes
Wheels
Aluminium rim/wire spoke
Front Wheel/Rim Size
19 inch
Front Tire Size
70/100-19
Rear Wheel/Rim Size
16 inch
Rear Tire Size
90/100-16
Front Brakes
220mm hydraulic disc with single-piston caliper and sintered metal pads
Rear Brakes
190mm hydraulic disc with single piston caliper and sintered metal pads
Born in Baja. Built for everywhere else. The CRF450R delivers championship-level off-road performance with trail-tuned precision and proven durability. With its six-speed gearbox, 19-inch rear wheel, it’s ready for everything from desert races to tight singletrack. If the trail doesn’t quit, neither will you.
Key Specifications
Engine Type
Liquid-cooled 4-stroke single cylinder uni-cam
Engine Capacity
449.7 cc / 27.4 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
1.66 US gallons / 6.3 L
Weight (Wet/Kerb)
243.8 lbs / 110.6 kg
Seat Height
37.8 inches / 961 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Honda CRF450RWE
Year
2025
Engine Type
Liquid-cooled 4-stroke single cylinder uni-cam
Displacement
449.7 cc / 27.4 cubic inches
Bore x Stroke
96.0 x 62.1 mm
Compression Ratio
13.5 : 1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Valve Train
Unicam® SOHC
Valves per Cylinder
n/a
Ø intake / exhaust valve dia
Ø throttle valve
Engine Management System
CDI Electronic Fuel injection (PGM-FI)
Fuel-mixture System
Lubrication System
Cooling System
Liquid Cooled
Ignition System
CDI
Fuel
Exhaust System
Emissions Compliance
Engine
Oil Capacity
1.25 Litres / 0.33 US gallons
Starter
Electric
Performance
Top Speed
n/a
Acceleration (0-100 km/h, 0-60 mph)
Fuel Consumption
Range
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet type multi-plate
Gearbox
Constant mesh
Primary Drive Ratio
Secondary Drive Ratio
Gear Ratios
Final Drive
Chain
Quick Shifter
Traction Control System
Assist & Slipper Clutch
Electrical & Electronics System
Battery
Alternator/Generator
Starter
Electric
Headlight Type
Taillight Type
Instrumentation
Connectivity
Riding Modes
Traction Control System
Launch Control
ABS
Cruise Control
Chassis & Suspension
Frame Type
Aluminium twin tube
Front Suspension
Showa 49mm USD fork
Front Suspension Travel
12.2 inches / 310 mm
Rear Suspension
Showa monoshock using Honda Pro-Link
Rear Suspension Travel
12.4 inches / 315 mm
Rake (Caster Angle)
27°19′ / 27.3°
Trail
4.53 inches / 115 mm
Rear Subframe
Swingarm
Handlebar
Steering Damper
Wheels & Brakes
Wheels
Aluminium spoke
Front Wheel/Rim Size
21 inch
Front Tire Size
80/100-21-51M Dunlop MX33F
Rear Wheel/Rim Size
19 inch
Rear Tire Size
120/80-19-63M Dunlop MX33
Front Brakes
Single 260mm disk
Rear Brakes
Single 240mm disk
ABS
Dimension & Weights
Overall Length
86.0 inches / 2183 mm
Overall Width
32.6 inches / 827 mm
Overall Height
49.8 inches / 1265 mm
Seat Height
37.8 inches / 961 mm
Wheelbase
58.3 inches / 1482 mm
Ground Clearance
13.1 inches / 333 mm
Fuel Tank Capacity
1.66 US gallons / 6.3 L
Wet (kerb/curb) Weight
243.8 lbs / 110.6 kg
Dry Weight
238.1 lbs / 108 kg
Max Load Capacity
Features
450cc Unicam® engine
Honda’s Unicam® design creates a compact engine that saves weight. The included valve angle flattens the combustion chamber for easier ignition while the camshaft sits lower, making it more compact and lowering the center of gravity.
Fuel injection
Our proven fuel injection system provides excellent torque, spot-on metering, and response, especially in the critical low-rpm range. Additionally, it automatically compensates for changes in elevation and weather.
Titanium intake and exhaust valves
Lightweight titanium intake and exhaust valves permit smaller valve springs, reducing overall engine height.
Twin-spar chassis
A lightweight, stiff, twin-spar aluminum chassis provides excellent handling while being wider than the standard MX frame to fit the six-speed transmission.
Dunlop MX52 tires
Dunlop’s MX52 tires provide excellent traction across various terrains and conditions, making them critical for on- and off-road bikes.
Low center of gravity
The Unicam® engine’s compact design and our center-of-mass engineering reduce the bike’s weight and improve handling.
Works-style front brake
Increased stopping power and handling are thanks to the compact twin-piston front brake caliper, anodized aluminum brake pistons, and lightweight 260mm front disc that minimize unsprung weight.
Works-style rear brake
An HRC works-style rear brake system uses a 240mm brake rotor that integrates with the rear master cylinder and fluid reservoir, eliminating the need for a separate reservoir and hose.
18-inch rear wheel
The 18-inch rear wheel provides a great selection of off-road tires, and the black DID rims add to the aesthetic appeal.
Wide-ratio six-speed transmission
Having six speeds in the transmission, as opposed to a typical five on an MX bike, provides more versatility. This bike can handle everything from East Coast rock crawling to wide-open Baja blasts.
Tuned-weight crank
The bike has a unique crankshaft that differs from our MX and dual-sport models. The crankshaft’s weight and inertial characteristics play a big role in power delivery.
Dual radiators
The dual radiators feature a refined core for superior heat dissipation. At the same time, the coolant recovery tank is in front of the engine between the frame downtubes for an improved center of gravity.
Oversized fuel tank
We gave the X model a larger, 2.0-gallon resin fuel tank. This will allow for fewer fuel stops, which can save valuable time over the course of a long ride or race.
Skid plate
The factory skid plate is light, yet it also offers the engine and lower-frame protection that serious riders demand on a machine like this.
Factory handguards
Designed exclusively for off-road riders and manufactured to Honda standards, these guards protect against rocks, branches, thorns, and brushes while giving the bike a polished look.
Works MX styling
If the X-model graphics remind you of our MX bikes, that’s because they’re derived from them. The smooth bodywork makes it easy to move around, while the in-mold graphics are durable, too.
Gear-driver counterbalancer
The gear-driven counterbalancer reduces vibration and drives the water pump.
California Green-Sticker compliant
California riders can ride this bike off-road year-round in any open OHV area since it is Green-Sticker compliant.
Superior ergonomics
Placing the rider’s legs at the narrowest part of the frame helps improve comfort and handling.
Sidestand
A sidestand may seem insignificant, but this forged alloy piece is an exceptional example of this bike’s attention to detail.
Fuel mileage meter
The fuel mileage meter is a key feature that displays current and average fuel mileage and fuel consumption and can show data in miles or kilometers. It’s in the same digital display as the speedometer, odometer, tripmeter, and clock.
Electric start
The electric start system ensures trouble-free starting. It drives the clutch side of the crankshaft, providing superior lubrication to starter gears while allowing a narrow engine with a short, strong crank.
Lighting package
It has a complete lighting package (headlight and taillight) for improved visibility in low-light conditions.
Honda CRF450RWE (2025) Color Options
Red
Subscribe to our Newsletter
Get the latest news and specifications delivered straight to your inbox — Subscribe now.
